A BCI is a communication channel with a biological end
Every stage between a neuron and a sentence loses or adds information. Bandwidth is what survives the whole chain, not what enters it.
Sample the neurons
Intent is distributed across large populations. An electrode sees a projection of that activity: a few nearby cells, a local field, or, from the scalp, a blur of millions.
- Measure
- Neurons or fields sampled, cortical area covered
- Failure boundary
- Sampling cortex that does not carry the intended variable, or too little of the cortex that does
What the record shows at this step
- Reported evidence
- Extracellular spikes are 50-500 µV close to a cell and vanish into background beyond about 150 µm; skull and scalp low-pass filter everything EEG records.
- Where it is moving
- Wider coverage of speech and hand cortex, including the sulcal banks that current arrays cannot reach.
- Principal risk
- Sampling cortex that does not carry the intended variable, or too little of the cortex that does
Evidence statements describe published studies and biophysics. “Where it is moving” is an editorial reading of direction, not an announced capability.
Couple electrode to tissue
Geometry and chemistry set how much signal reaches the contact. The boundary is alive: it scars, shifts, and changes which cells a contact hears.
- Measure
- Impedance, usable channel yield, signal-to-noise
- Failure boundary
- Scar tissue, micromotion, and unit turnover that make the signal drift even when the hardware works
What the record shows at this step
- Reported evidence
- Across 14 BrainGate participants, arrays recorded spiking on an average 35.6% of electrodes, for up to 7.6 years.
- Where it is moving
- Softer materials and designs that trade some selectivity for decade-long stability.
- Principal risk
- Scar tissue, micromotion, and unit turnover that make the signal drift even when the hardware works
Evidence statements describe published studies and biophysics. “Where it is moving” is an editorial reading of direction, not an announced capability.
Amplify and digitise
Microvolt signals must be amplified against thermal noise, muscle artefact, and mains hum, then sampled fast enough to catch a spike.
- Measure
- Input-referred noise, common-mode rejection, power per channel
- Failure boundary
- Front-end power that scales with channel count inside a sealed, heat-limited package
What the record shows at this step
- Reported evidence
- Thermal noise at a typical microelectrode is several microvolts, which already sets the ceiling on extracellular signal-to-noise.
- Where it is moving
- Sub-microwatt analogue feature extraction on the implant itself.
- Principal risk
- Front-end power that scales with channel count inside a sealed, heat-limited package
Evidence statements describe published studies and biophysics. “Where it is moving” is an editorial reading of direction, not an announced capability.
Compress and transmit
Raw waveforms from a thousand channels are hundreds of megabits a second. Fully implanted systems extract features first and send a thousandth of that.
- Measure
- Transmitted rate, energy per bit, implant temperature rise
- Failure boundary
- Compression is irreversible: what the implant discards, no later decoder can recover
What the record shows at this step
- Reported evidence
- Threshold crossings and spike-band power carry most of the decodable information, which is why high-performance speech systems use them.
- Where it is moving
- Implanted wireless packages that replace the percutaneous connector without losing decoding performance.
- Principal risk
- Compression is irreversible: what the implant discards, no later decoder can recover
Evidence statements describe published studies and biophysics. “Where it is moving” is an editorial reading of direction, not an announced capability.
Decode the intent
A model estimates a latent variable: cursor velocity, a letter, a phoneme. Neural representations overlap and drift, so the decoder makes substitution and timing errors.
- Measure
- Raw phoneme or character error, latency, calibration data required
- Failure boundary
- Drift across days that silently degrades a fixed decoder
What the record shows at this step
- Reported evidence
- A fixed brain-to-voice decoder degraded noticeably within about two weeks; a fixed typing decoder reached 12-15% word error within days.
- Where it is moving
- Self-supervised recalibration during ordinary use, and models pretrained across many people.
- Principal risk
- Drift across days that silently degrades a fixed decoder
Evidence statements describe published studies and biophysics. “Where it is moving” is an editorial reading of direction, not an announced capability.
Apply a language prior
A language model turns noisy symbol estimates into probable sentences. It is the reason speech BCIs work, and the reason their accuracy cannot all be credited to the brain.
- Measure
- Error before and after the language model, accuracy on improbable sentences
- Failure boundary
- Fluent output that reflects what was likely rather than what was meant
What the record shows at this step
- Reported evidence
- Handwriting decoding at about 94% raw character accuracy rose to over 99% with a language model; the 2026 typing system used a 5-gram model.
- Where it is moving
- Evaluation on names, novel words, and adversarially unlikely sentences, not only familiar corpora.
- Principal risk
- Fluent output that reflects what was likely rather than what was meant
Evidence statements describe published studies and biophysics. “Where it is moving” is an editorial reading of direction, not an announced capability.
A system can need tens of megabits a second of neural waveforms to recover a few tens of bits a second of human intention. That is not waste. It is the price of inferring a quiet variable from loud biology.
Megabits in, tens of bits out
An implant digitises millions of samples a second to recover a message worth a few tens of bits. That ratio is not waste; it is what inferring a low-dimensional intention from redundant biology costs. What limits the implant is the heat of moving those samples.
14% of a ~70 mW heat envelope
- Front end
- 5.1 mW
- Radio
- <0.1 mW
- On-implant processing
- 5 mW
- Samples per intended bit
- ~345,493
Compression cuts the transmitted stream by about 3,600×. It is irreversible: waveform shape is discarded, so the implant can no longer separate neighbouring neurons on one contact. At 256 channels the front end alone uses 5 mW; the heat ceiling becomes a per-channel power ceiling.
Why output outran electrodes
From 2006 to 2024, most human records used the same kind of 96-electrode silicon array. The hardware barely changed; the representation being decoded changed completely.
The decoded variable changed
Cursor control asks motor cortex to act as a joystick. Handwriting and speech ask it to do what it evolved for: produce rich sequences of distinct gestures. Letters and phonemes are easier to tell apart than cursor directions, so the same electrodes carry more usable information.
Nearby neurons are redundant
Cortex coordinates movement through low-dimensional population dynamics. Ten to thirty latent factors often capture most of the variance in a hundred-electrode recording, so each added contact in the same patch adds less new information.
Language supplies the rest
Words are not equiprobable. A language model resolves ambiguous phonemes from context, which is why 62 words a minute did not need hundreds of thousands of independent channels.
Hardware scaling is heavy
Every added channel costs amplifier power, telemetry, packaging, surgical footprint, and a new failure point, inside a skull that cannot shed much heat. Software improvements cost none of these.
A 2026 typing study made the point directly. With about 140 randomly chosen electrodes, attempted typing produced 9.5% word error while attempted handwriting produced 27%. Same participant, same electrodes, different amounts of usable information.
The software dividend has a limit. A decoder cannot recover information absent from the signal, and Shannon’s bound, C = B log2(1 + SNR), applies to the neural link as to any other. As the signal thins, a larger model learns priors instead of intent.
Implant lifetime is not signal lifetime
The operational question is not whether the same neuron stays on the same wire, but whether the decoder stays matched to a slowly moving population. Adaptive decoding and biological stability are substitutes up to a point, and only up to that point: if contacts fail or signal-to-noise falls irreversibly, no recalibration can restore the missing dimensions.
The discovery chain
Progress came in discontinuous changes of representation: switch, cursor, arm, handwriting, phoneme, voice. Each one reset the rate while the sensor stayed roughly the same.
- 1973
Evoked potentials as a switch
Vidal showed that scalp-recorded visual responses could drive a computer selection, establishing the closed loop without muscles.
- 1988
The P300 speller
Farwell and Donchin spelled by attention to flashing letters. One to two words a minute set the non-invasive baseline for two decades.
- 2006
Intracortical cursor control
A 96-electrode Utah array let a person with tetraplegia move a cursor, open email, and operate a television, years after injury.
- 2012-2013
Robotic arms
Participants reached, grasped, and drank from a bottle with a robotic arm; a second group achieved seven-dimensional control.
- 2021
Handwriting and touch
Decoding attempted handwriting reached 90 characters a minute. Separately, stimulated touch halved object-handling time with a robotic arm.
- 2023
Speech
Intracortical speech reached 62 words a minute and surface ECoG 78, both with roughly a quarter of words wrong on open vocabularies.
- 2024-2026
From records to routine
97.5% accuracy over months, then more than 3,800 hours of independent use at home: the first long stretch of the curve measured outside a laboratory.
Writing to the brain is a different problem
Reading can average many noisy channels into one confident estimate. Writing cannot: injected current spreads through tissue, neighbouring contacts interact, and forcing hundreds of neurons to fire together is nothing like the sparse, precisely timed activity of natural sensation. Charge is also bounded by tissue safety at each contact.
Stimulation resolution should be counted in distinguishable percepts and task improvement, not electrodes or pulse rates. A deep-brain stimulator delivers over a hundred pulses a second and transmits no semantic bits at all; it is a controller, not a channel.
Who is building what
Academic consortia hold most of the peer-reviewed human evidence. Companies are building the implantable packages that deployment requires. Search the record, or filter by interface.
BrainGate consortiumBrainGate2 pilot trialUtah arrays in motor and speech cortex with percutaneous connectors
- Reported evidence
- Twenty years of human data, from 2006 cursor control to 2026 home speech; across its first 14 participants, arrays recorded spiking on an average of 35.6% of electrodes for up to 7.6 years.
- Announced next step
- Fully implanted wireless hardware and unsupervised recalibration for daily use.
- Unresolved risk
- A connector through the skull, researcher-built systems, and a small cohort whose best results come from a few participants.
UC Davis Neuroprosthetics LabSpeech neuroprosthesis256 electrodes in ventral precentral gyrus decoded to text and synthesised voice
- Reported evidence
- 97.5% word accuracy over 8.4 months; later more than 3,800 hours of independent home use at an average 56.1 words a minute; brain-to-voice synthesis with about 10 ms of neural-to-voice computation.
- Announced next step
- Instantaneous expressive voice, and replication in more participants.
- Unresolved risk
- A fixed voice decoder degraded noticeably within about two weeks; results rest on one long-term participant.
Stanford Neural Prosthetics Translational LabHandwriting, speech, and typing decodersRepresentation-first decoding: handwriting, phonemes, and attempted finger movements
- Reported evidence
- 90 characters a minute from attempted handwriting (2021) and 62 words a minute from attempted speech (2023) on essentially the same class of array.
- Announced next step
- Open-vocabulary accuracy and lower calibration burden.
- Unresolved risk
- Language-model priors can make fluent output that the neural signal did not uniquely specify.
UCSF Chang LabHigh-density ECoG speech253-electrode surface grid over speech sensorimotor cortex
- Reported evidence
- Median 78 words a minute with text, synthesised audio, and avatar output after under two weeks of training.
- Announced next step
- Higher accuracy and longer-term stability from the cortical surface.
- Unresolved risk
- Around 25% word error at record speed; one participant and a craniotomy.
SynchronStentrodeElectrode array delivered through the jugular vein into a cortical vein
- Reported evidence
- First-in-human studies in people with severe paralysis delivered a thought-controlled digital switch for ordinary computer tasks, with no open brain surgery.
- Announced next step
- Larger pivotal trials for assistive computer control.
- Unresolved risk
- Distance from neurons caps bandwidth at clicks and selections; vascular-device risks replace craniotomy risks.
Precision NeuroscienceLayer 7 cortical interfaceThin-film high-density surface electrodes inserted through a narrow skull slit
- Reported evidence
- Temporary high-density recordings during neurosurgery; a regulatory clearance for short-term use was reported in 2025.
- Announced next step
- Chronic implanted communication systems.
- Unresolved risk
- Short-term intraoperative data does not establish chronic communication performance.
NeuralinkN1 / PRIME studyRobot-inserted flexible polymer threads with 1,024 electrodes and a fully implanted wireless package
- Reported evidence
- Participants have used cursor control at home; in the first participant most threads retracted after implantation, and the company compensated in software.
- Announced next step
- Speech decoding, more participants, and higher channel counts.
- Unresolved risk
- Peer-reviewed, long-duration communication outcomes are not yet published on the same curve as academic systems.
ParadromicsConnexusDense microwire bundles with integrated electronics for 1,600+ channels
- Reported evidence
- High-channel-count microwire recording, with a first brief in-human recording reported in 2025.
- Announced next step
- A chronic speech-restoration trial.
- Unresolved risk
- Channel count must translate into stable independent dimensions, inside a power and heat budget.
Blackrock NeurotechUtah arrayRigid silicon microelectrode arrays
- Reported evidence
- The sensor behind most human intracortical BCI records from 2006 to 2026.
- Announced next step
- Higher channel counts and implanted wireless versions.
- Unresolved risk
- An eight-order-of-magnitude stiffness mismatch with brain tissue drives micromotion and scarring.
University of Pittsburgh Rehab Neural Engineering LabsBidirectional motor and touch BCIIntracortical microstimulation of somatosensory cortex for artificial touch
- Reported evidence
- Adding stimulated touch halved median object-transfer time with a robotic arm compared with vision alone.
- Announced next step
- Richer, more natural tactile percepts.
- Unresolved risk
- Stimulation evokes buzzing or tingling rather than texture; percepts interact as contacts are added.
Feinstein InstitutesDouble neural bypassIntracortical decoding coupled to patterned spinal and cortical stimulation
- Reported evidence
- A 2026 participant with severe tetraplegia regained functional object manipulation with persistent gains in movement and sensation.
- Announced next step
- Closed-loop restoration that improves the underlying function.
- Unresolved risk
- Better analysed as a controller than a channel; generalisation beyond single participants is unproven.
Cochlear implantsClinical standard of care16 to 22 electrodes along the auditory nerve's frequency map
- Reported evidence
- The most successful neuroprosthesis, restoring speech comprehension to more than a million people with a sparse engineered code.
- Announced next step
- Better music and noise performance.
- Unresolved risk
- A reminder, not a template: a few contacts are useful, but they are not equal to natural hearing.
Company capabilities are reproduced from publications and public announcements. Installed contact counts are not usable channels, and an announced trial is not a published outcome.
The unit that matters is correct words per day
A peak rate describes a session. The rate a person experiences is set by how many hours the system works, how much of it is spent recalibrating, and how many words come out wrong.
How many correct words survive a day?
A record is set in a session. A life is lived in days. Useful bandwidth is correct information divided by all the time it took, including calibration and downtime.
≈ 8.4 bit/s averaged over a sixteen-hour waking day
- At full rate, all hours
- 22,176
- Lost to calibration
- 0
- Lost to downtime
- 1,109
- Lost to errors
- 632
An average adult speaks on the order of ten to twenty thousand words a day. Try the laboratory record against home use: a faster system used briefly with a quarter of its words wrong delivers far less than a slower one available all day.
Calculation & assumptions
Correct words per day = rate × 60 × (hours in use − calibration) × availability × (1 − word error rate). The waking-day figure converts correct words to an upper-bound bit rate at five characters a word and log₂27 bits a character, then spreads it across sixteen hours.
Only the home-use hours are derived from the record: about 3,800 hours across roughly 19 months is about 6.6 hours a day. Session lengths, calibration minutes, and availability in the other scenarios are illustrative. Word error in the home-use scenario is set between the >99% prompted accuracy and the 92.3% of free sentences rated mostly correct.
What pushes useful bandwidth up next
Decoders that track drift
Unsupervised recalibration during ordinary use turns a slowly changing signal into a stable interface without anyone present.
Condition: adaptation that does not also learn the user’s errorsFully implanted packages
Wireless, sealed devices remove the percutaneous connector, the largest barrier to living with a BCI outside a study.
Condition: on-implant compression that keeps the features speech decoding needsWider, not denser, coverage
Sampling more of speech and hand cortex, including sulcal banks, adds new dimensions where adding contacts to one patch adds redundancy.
Condition: effective dimensionality that actually rises with added coverageModels that transfer between people
Pretraining on pooled recordings could shrink calibration from hours to sentences for each new participant.
Condition: enough multi-site data, shared under consent terms that allow itThe remaining constraints are biological and logistical
The field has moved from detecting a controllable signal, to decoding symbols quickly, to stabilising across days. The leading systems are working on the next two steps: years of independent use, and implantation routine enough to deploy.
Chronic stability
Implants survive for years while the neurons they hear change. Drift is gradual and measurable, and a decoder that is not continuously adapted loses accuracy in days to weeks.
Calibration burden
Every supervised minute of recalibration is subtracted from useful bandwidth and requires someone else to be present. Zero-calibration daily use is the target that matters most for independence.
The heat budget
A skull-mounted implant can dissipate only tens of milliwatts before warming tissue. Channel count therefore becomes a power-per-channel problem, and raw streaming is ruled out.
Surgery and hardware
Percutaneous connectors, craniotomies, and specialist centres limit who can receive a device. Deployment, not decoding, sets how many people the curve reaches.
The language-model question
Fluent output can hide weak neural evidence. Without evaluation on improbable sentences, accuracy figures cannot separate what the brain said from what the model guessed.
Cohort scale
The strongest results come from a handful of people. A one-participant record is evidence of possibility, not a platform.
An optimistic view, with conditions
Restoring conversation does not require reading thought
Speech cortex does not need to reveal every representation in the brain. It needs to supply enough stable information about attempted articulation for a sequence model to pick the intended sentence. The evidence through 2026 shows that a few hundred well-placed electrodes can already meet that narrower goal, in a few people.
The threshold for consequence
For many people with locked-in paralysis, 20-30 words a minute at low single-digit error, sub-second latency, no daily calibration, and all-day availability would transform communication. The 2026 results meet parts of that in individual participants.
Reproducible, implanted, wireless
The same performance across dozens of participants, from sealed devices, with years of stability and a procedure that does not require a research hospital.
Natural speed and a return channel
120-160 words a minute at conversational accuracy, about 40 bits a second, plus stimulation that supplies touch and proprioception good enough to close fine motor loops.
View the annual scorecard
| Metric | Record through September 2026 | Parity with natural function |
|---|---|---|
| Conversational rate | 32 wpm sustained over months; 56 wpm averaged at home; 78 wpm laboratory peak | 120-160 wpm |
| Open-vocabulary error | 23.8% WER at 125,000 words (2023); >99% on prompted sentences at home (2026) | Under 3% in unprompted conversation |
| Daily calibration | Minutes of supervised retraining to none in the best home system | Zero, with background adaptation |
| Independent use | 3,800+ hours over ~19 months, one participant | All-day, across many participants |
| Usable channel lifetime | Spiking on ~36% of electrodes, arrays recording up to 7.6 years | A decade, without revision surgery |
| Write resolution | Tactile percepts that aid control; a few dozen phosphenes from 96 contacts | Distinguishable percepts that scale with contacts |
Baselines are reported results, most from single participants. Parity targets are editorial benchmarks derived from natural speech and typing, not forecasts.
There is more than one finish line
- Signal detectedA controllable neural signal can drive a binary choice.
- Symbols decodedLetters, phonemes, or words decoded at useful speed in a session.
- Stable across daysAccuracy holds without supervised retraining.
- Independent for yearsA person uses it all day, at home, without researchers.
- ReproducibleThe same result across many people and centres.
- DeployableImplanted wirelessly through a routine procedure and paid for.
Sources, method, and boundaries
Figure 1 plots rates as reported by each study, converted to words per minute at five characters a word where needed; it is not a benchmark series, and the points differ in vocabulary, error, protocol, and participant. Figures 3 and 4 are illustrative models rather than measurements. Bit rates for text are upper bounds that treat 26 letters and a space as equiprobable; real English carries less information per character. Nothing here is clinical advice.
- Physical channel
- An implanted contact, whether or not it records a usable signal.
- Usable channel
- A contact meeting a stated signal-quality or task-tuning criterion at a given time after implantation.
- Word error rate
- Substitutions, insertions, and deletions divided by words intended, usually measured after a language model.
- Useful bandwidth
- Correct information delivered per unit of total time, including calibration and downtime.
Read More
The 20 books most relevant to this report, drawn from the reading lists of people worth listening to, via TopBooks.
The Future of the Mind: The Scientific Quest to Understand, Enhance, and Empower the MindMichio KakuRecommended by Dominic Steil
On IntelligenceJeff Hawkins, Sandra BlakesleeRecommended by David Eagleman, Ev Williams +5
Irreducible MindBruce Greyson, Edward F. KellyRecommended by Tim Ferriss
You Are Not a GadgetJaron LanierRecommended by Ev Williams, Ryan Holiday +2
Power Up Your Brain: The Neuroscience of EnlightenmentDavid PerlmutterRecommended by Andrew Weil
The Predictive MindJakob HohwyRecommended by Lisa Feldman Barrett
Principles of Neural DesignSimon Laughlin, Peter SterlingRecommended by Lisa Feldman Barrett
Surfing Uncertainty: Prediction, Action, and the Embodied MindAndy ClarkRecommended by Lisa Feldman Barrett
After Phrenology (How to Study the Brain)Michael L. AndersonRecommended by Lisa Feldman Barrett
The Better Brain BookDavid PerlmutterRecommended by Andrew Weil
Zen and the Brain: Toward an Understanding of Meditation and ConsciousnessJames H. AustinRecommended by Ari Iaccarino
Brain ArchitectureLarry W. SwansonRecommended by Jordan Peterson, Lisa Feldman Barrett
Glimpses of Heaven, Visions of Hell: Virtual Reality and Its ImplicationsBarrie Sherman, Phillip JudkinsRecommended by Walter OÕBrien
Phantoms in the BrainV. S. Ramachandran, Sandra BlakesleeRecommended by Cleo Abram, Tom Bilyeu
The Brain from Inside OutGyörgy BuzsákiRecommended by Oxford University Press
ProjectionsKarl DeisserothRecommended by Abraham Verghese, Daniel Levitin +1
Brain Wash: Detox Your Mind for Clearer Thinking, Deeper Relationships, and Lasting HappinessDavid Perlmutter, Austin PerlmutterRecommended by Gretchen Rubin, Rudolph E. Tanzi
The Mindful Therapist: A Clinician's Guide to Mindsight and Neural IntegrationDaniel SiegelRecommended by Daniel Gottlieb, John C. Norcross +1
The Distracted Mind: Ancient Brains in a High-Tech WorldAdam Gazzaley, Larry D. RosenRecommended by Charles Best, Jack Kornfield
The Emotional BrainJoseph E. LeDouxRecommended by Jordan Peterson
